Beschrijving T60S opschepmachine
Type | T60S | |
capaciteit tot (ton/u) | 80 | |
bandbreedte opneemband | 550 | |
bandbreedte telescoopband | 600 | |
werkbereik (m²) | 250 | |
lengte opneemwagen | B | 3390 |
telescoop ingeschoven | C | 4080 |
telescoop uitgeschoven | 9260 | |
uitschuiflengte | 5180 | |
maximale machinehoogte | D | 1500 |
maximale hoogte telescoop | E | 1110 |
maximale breedte | F | 1080 |
bandsnelheid opneemband (m/s) | 0,56 | |
bandsnelheid telescoopband (m/s) | 1,0 | |
aandrijving wagen (kW) | 2x 1,1 | |
aandrijving opneemband (kW) | 1,5 | |
aandrijving telescoopband (kW) | 2,2 | |
gewicht opneemband (kg) | 760 | |
gewicht telescoopband (kg) | 1050 |
Alle maten in mm
Opties |
T60S |
zijschilden beweegbaar | standaard |
afslagschakelaar | |
afstandsbediening | |
afstandsbediening draadloos | |
tweetoeren trommelmotor mp | |
graanuitvoering T60L-T60S | |
graanuitvoering T40L | – |
T60L indringkracht vergroter | – |
uiengrijper, los geleverd | |
uiengrijper montage op T60L – T60S | |
schraper opneemband T40L | – |
schraper opneemband T60L – T60S | |
schraper telescoopband T40L | – |
schraper telescoopband T60L – T60S |
